Detailed Technical Specifications

Product Information

• Product Name: HP ZBook 15u G3 Mobile Workstation
• Model: ZBook 15u G3
• Brand: HP
• Series: ZBook (Professional Workstation Series)
• Category: Mobile Workstation (Thin and Light)
• Release Year: 2017
• Form Factor: 15.6-inch Laptop
• Dimensions: 14.88 x 10.08 x 0.78 inches (378 x 256 x 19.8 mm)
• Weight: Starting at 4.14 lbs (1.88 kg)
• Color: Silver or Dark Ash Silver (depending on configuration)

Processor (CPU) Options

• Intel Options:
  • Intel Core i5-7200U (7th Gen, 2 cores, 4 threads, 2.5-3.1GHz)
  • Intel Core i5-7300U (7th Gen, 2 cores, 4 threads, 2.6-3.5GHz)
  • Intel Core i7-7500U (7th Gen, 2 cores, 4 threads, 2.7-3.5GHz)
  • Intel Core i7-7600U (7th Gen, 2 cores, 4 threads, 2.8-3.9GHz)
• AMD Options (Select Configurations):
  • AMD Ryzen 5 PRO 2500U (4 cores, 8 threads, 2.0-3.6GHz)
  • AMD Ryzen 7 PRO 2700U (4 cores, 8 threads, 2.2-3.8GHz)
• Cache: 3MB (i5) or 4MB (i7) Intel Smart Cache
• Socket: BGA (soldered to motherboard)
• TDP: 15W (Intel U-series) or 15W (AMD PRO series)
• Architecture: 14nm (Intel Kaby Lake) or 14nm (AMD Zen)
• Technologies: Intel vPro (on Intel configurations), AMD GuardMI (on AMD configurations)

Display Options

• Size: 15.6-inch diagonal
• Panel Options:
  • FHD IPS Anti-Glare (1920x1080) - 250 nits
  • FHD IPS Anti-Glare DreamColor (1920x1080) - 400 nits, 100% sRGB
  • UHD IPS Anti-Glare (3840x2160) - 400 nits, 100% Adobe RGB (on select configurations)
• Touch Options: Available on some configurations (10-point multi-touch)
• Bezel: Thin bezel design (for improved screen-to-body ratio)
• Color Gamut: 45% NTSC (standard) or 72% NTSC/100% sRGB (DreamColor)
• Viewing Angles: 178° horizontal and vertical (IPS panels)

Graphics Options

• Integrated Graphics (Intel models): Intel HD Graphics 620
• Dedicated Graphics: AMD Radeon Pro WX 3100 (2GB GDDR5)
• AMD Graphics Specifications:
  • Stream Processors: 512
  • Memory: 2GB GDDR5
  • Memory Interface: 64-bit
  • Memory Bandwidth: 48 GB/s
  • DirectX Support: 12
  • OpenGL Support: 4.5
  • OpenCL Support: 2.0
• Integrated Graphics (AMD models): AMD Radeon Vega 8 or Vega 10 (depending on CPU)
• ISV Certifications: Certified for professional applications (AutoCAD, SolidWorks, etc.)

Memory (RAM)

• Type: DDR4-2133 or DDR4-2400 (non-ECC)
• Slots: 2x SODIMM slots (user accessible)
• Standard Configurations: 4GB, 8GB, 16GB (1x or 2x modules)
• Maximum Supported: 32GB (2x16GB)
• Memory Technology: Dual-channel architecture (when using 2 identical modules)
• Speed: 2133MHz (Intel 7th Gen) or 2400MHz (AMD Ryzen models)

Storage Options

• Interface Options:
  • SATA 6Gb/s (for 2.5-inch drives)
  • PCIe Gen 3.0 x4 NVMe (for M.2 drives)
• Form Factors:
  • 2.5-inch drive bay (SATA HDD/SSD)
  • M.2 2280 slot (PCIe NVMe SSD or SATA SSD)
• Capacity Options:
  • 500GB/1TB/2TB 7200RPM SATA HDD
  • 128GB/256GB/512GB/1TB PCIe NVMe SSD
  • 128GB/256GB/512GB SATA SSD
  • Intel Optane Memory (16GB/32GB) acceleration available
• RAID Support: Not available (single drive configurations only)

Operating System

• Pre-installed: Windows 10 Pro 64-bit
• Downgrade Option: Windows 7 Professional 64-bit (available at launch)
• Recovery: HP Cloud Recovery, HP Recovery Manager
• Windows Features: BitLocker, Remote Desktop, Group Policy, Domain Join
• Windows 11 Compatibility: Limited - 7th Gen Intel may not meet official requirements
• Linux Options: Certified for certain Linux distributions (Ubuntu, RHEL)

Connectivity

• Ethernet: Realtek RTL8111HSH Gigabit Ethernet (10/100/1000)
• Wireless: Intel Dual Band Wireless-AC 8265 (802.11ac, 2x2) + Bluetooth 4.2
• Wireless Options: Intel Wi-Fi 6 AX200 (on some later configurations)
• Mobile Broadband: Optional LTE-Advanced (Fibocom L830-EB or similar)
• Wi-Fi Speed: Up to 867 Mbps (5GHz) or 300 Mbps (2.4GHz)
• Bluetooth: Bluetooth 4.2 with A2DP, LE support

Ports & Connectors

• Left Side:
  • 1x USB 3.1 Gen 1 Type-C (with DisplayPort 1.2)
  • 1x USB 3.1 Gen 1 Type-A (with charging)
  • 1x HDMI 1.4b
  • 1x VGA port
  • 1x 3.5mm headphone/microphone combo jack
  • Smart Card reader (optional)
• Right Side:
  • 2x USB 3.1 Gen 1 Type-A
  • 1x RJ-45 Ethernet
  • 1x AC power connector
  • Kensington lock slot
• Docking: HP USB-C Dock G5 compatible, traditional docking port (optional)

Audio

• Audio System: Audio by Bang & Olufsen
• Speakers: Dual stereo speakers
• Speaker Power: 2W per speaker
• Audio Codec: Realtek ALC3246
• Microphone: Dual array digital microphones
• Audio Features: HP Noise Cancellation Software, DTS Studio Sound

Camera & Communication

• Webcam: HP Wide Vision HD camera (720p)
• Camera Features: Temporal noise reduction, low-light enhancement
• IR Camera Option: Available for Windows Hello facial recognition
• Microphone: Dual array digital microphones with noise reduction

Keyboard & Input

• Keyboard: Full-size spill-resistant keyboard with numeric keypad
• Key Travel: 1.5mm
• Backlight: White LED backlight (standard on most configurations)
• Pointing Device: HP ImagePad with multi-touch gesture support
• Touchpad Size: 105 x 70 mm
• Additional Buttons: Dedicated mouse buttons above touchpad

Power & Battery

• Battery Type: 3-cell, 56Wh Li-ion polymer
• Battery Options: Optional 6-cell, 83Wh battery
• Battery Life: Up to 10 hours (MobileMark 2014) with standard battery
• Power Adapter: 65W or 90W Smart AC adapter
• Charging: Supports fast charging (90% in 90 minutes)
• Battery Care: HP Battery Health Manager in BIOS

Security Features

• TPM: TPM 2.0 embedded security chip
• Fingerprint Reader: Integrated fingerprint reader (optional)
• Smart Card Reader: Optional contact smart card reader
• BIOS Security: HP Sure Start Gen4, Secure Boot, BIOS passwords
• HP Security Features: HP DriveLock, HP BIOS Configuration Utility
• Physical Security: Kensington lock slot, chassis intrusion detection
• Intel Security: Intel vPro with AMT (on Intel configurations)

Software & Management

• Pre-installed Software: HP Support Assistant, HP Performance Advisor, HP Client Security Manager
• Management: HP Manageability Integration Kit, compatible with HP Device Manager
• Remote Management: Intel AMT 11.0 (on Intel vPro models)
• Cloud Management: Compatible with Microsoft Endpoint Manager
• Workstation Software: HP Remote Graphics Software (RGS) optional

Environmental Specifications

• Operating Temperature: 50°F to 95°F (10°C to 35°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Relative Humidity: 10% to 90% (non-condensing)
• Altitude: Up to 15,000 feet (4,572 meters)
• Acoustic Noise: 32 dBA typical (idle), 38 dBA under load

Warranty & Support

• Standard Warranty: 3-year limited warranty (parts, labor, and onsite service)
• Support Hours: 24/7 for critical issues, business hours for others
• Onsite Service: Next business day (in supported locations)
• Extended Warranty: Available up to 5 years
• Accidental Damage Protection: Optional HP Care Pack

Certifications & Compliance

• ISV Certified (AutoCAD, SolidWorks, Revit, etc.)
• MIL-STD 810G tested
• ENERGY STAR 7.0 certified
• EPEAT Gold (depending on configuration)
• RoHS compliant
• WEEE compliant
• FCC Class B certified
• CE Marking

What's in the Box

• HP ZBook 15u G3 Mobile Workstation
• 65W or 90W Smart AC adapter
• Power cord (region specific)
• Documentation kit
• Warranty card

Performance & Professional Use

• Target Use: Professional CAD, engineering, architecture, finance, content creation
• Recommended For: Engineers, architects, designers, financial analysts, researchers
• Graphics Performance: Radeon Pro WX 3100 suitable for entry-level CAD and 3D modeling
• CPU Performance: Good for multitasking and moderate computational tasks
• Not Recommended For: High-end 3D rendering, complex simulations, scientific computing
• Professional Software: Certified for AutoCAD, SolidWorks, Revit, CATIA, CREO, etc.

Upgrade Potential

• RAM Upgrade: Easy access panel, supports up to 32GB DDR4
• Storage Upgrade: Can upgrade both 2.5-inch drive and M.2 SSD
• Wi-Fi Upgrade: M.2 Wi-Fi card is replaceable with newer standards
• Battery Upgrade: Can upgrade to higher capacity battery
• Limitations: CPU and GPU are soldered, not upgradeable

Important Notes & Recommendations

• Processor Selection: Consider AMD Ryzen models for better multi-threaded performance
• Memory Configuration: Minimum 16GB recommended for professional applications
• Storage: PCIe NVMe SSD significantly improves application loading times
• Display: DreamColor display recommended for color-critical work
• Graphics: Radeon Pro WX 3100 is entry-level workstation GPU; consider higher ZBooks for demanding work
• Windows 11: Verify compatibility requirements if planning to upgrade
• Compared to ZBook 15 G3: 15u is thinner/lighter with U-series CPUs vs H-series in regular 15 G3
• Compared to ZBook 17 G3: 15u is more portable but has less powerful components
• Docking: Consider HP USB-C Dock for multi-monitor setup and connectivity
• Value Proposition: Entry-level mobile workstation with professional features and certifications
