Performance Specifications

Speed & Interface

• Sequential Read Speed: Up to 7,400 MB/s (Maximum)
• Sequential Write Speed: Up to 6,800 MB/s (Maximum)
• Random Read IOPS (4KB): Up to 1,000,000
• Random Write IOPS (4KB): Up to 950,000
• Data Transfer Interface: PCIe Gen4 x4, backward compatible with PCIe Gen3 x4

Reliability & Endurance

Durability Metrics

• TBW (Total Bytes Written): 600 TBW (TeraBytes Written)
• MTBF (Mean Time Between Failures): 1,800,000 hours
• DWPD (Drive Writes Per Day): Approximately 0.33 DWPD (based on 5-year warranty and 1TB capacity)

Power & Thermal Management

Power Consumption

• Active Power (Typical): 5.5W (Read/Write operations)
• Idle Power: 30mW
• Sleep/PS4 Power State: < 5mW
• Operating Voltage: 3.3V ±5%

Thermal & Environmental

• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Thermal Throttling: Dynamic thermal management
• Operating Humidity: 5% to 95% RH (Non-condensing)

Features & Compatibility

Key Features

• NVMe Protocol: NVMe 1.4 compliant
• TRIM Support: Yes
• S.M.A.R.T. Support: Yes
• Advanced Wear Leveling: Yes
• Error Correction: LDPC ECC with RAID engine
• Bad Block Management: Advanced BBM
• Power Loss Protection: Hardware-based PLP
• Encryption: AES 256-bit hardware encryption

Compatibility

• Operating Systems: Windows 10/11, Linux, macOS (with appropriate drivers)
• Motherboard Compatibility: Requires M.2 slot with PCIe 4.0 x4 support
• Applications: High-performance computing, gaming, video editing, data centers, workstations

Warranty & Physical Specifications

Warranty Information

• Warranty Period: 5 years limited warranty
• Warranty Terms: Based on TBW rating or time period, whichever comes first

Physical Dimensions

• Dimensions (L × W × H): 80.0 mm × 22.0 mm × 2.4 mm (single-sided)
• Weight: Approximately 8g (0.28 oz)
• Key Type: M-Key (M.2 PCIe)

Included Accessories

• M.2 mounting screw (varies by packaging)
• Installation guide

Additional Notes

• Requires PCIe 4.0 compatible motherboard for maximum performance
• Backward compatible with PCIe 3.0 slots at reduced speeds
• Heatsink not included (check specific model variants)
• Ideal for applications requiring ultra-fast data transfer speeds
• Performance may vary based on system configuration and thermal conditions
