Detailed Technical Specifications

Product Information

• Product Name: oraimo Watch 5 Panda Glass Smart Watch
• Model: Watch 5 (Panda Glass edition)
• Brand: oraimo (Accessories brand by Transsion Holdings)
• Series: Watch 5 Series
• Category: Smart Watch / Fitness Tracker
• Release Year: 2022-2023
• Dimensions: 45mm x 37mm x 11mm (approximate)
• Weight: 40-48 grams (without strap)
• Strap Material: Silicone (standard), quick-release mechanism
• Strap Width: 22mm (interchangeable with standard 22mm watch bands)
• Colors Available: Black, Blue, Pink, Green (case and strap combinations)

Display

• Screen Size: 1.85-inch diagonal (47mm)
• Display Type: TFT LCD with full-touch capacitive screen
• Resolution: 240x286 pixels
• Aspect Ratio: Approximately 1.2:1 (rectangular display)
• Brightness: 450-500 nits (adjustable with 5 levels)
• Color Depth: 16-bit (65,536 colors)
• Screen Protection: Panda Glass (enhanced tempered glass protection)
• Glass Technology: Panda Glass - similar to Corning Gorilla Glass, offers improved scratch and impact resistance
• Always-On Display: Yes (select watch faces support always-on mode)
• Touch Type: Capacitive multi-touch with gesture support
• Bezel: Ultra-thin bezels for maximum screen-to-body ratio

Processor & Memory

• Processor: Nordic Semiconductor nRF52840 or equivalent wearable chipset
• CPU Architecture: ARM Cortex-M4 with FPU
• Clock Speed: 64 MHz (optimized for low power consumption)
• RAM: 64MB DDR
• Internal Storage: 32MB flash storage
• Operating System: Proprietary RTOS (Real-Time Operating System) optimized for wearables
• UI Navigation: Touch screen + single physical button for home/back functions

Battery & Charging

• Battery Type: Lithium polymer rechargeable battery
• Capacity: 300mAh (typical for Watch 5 series)
• Battery Life:
  • Typical Use: 7-10 days (heart rate monitoring, notifications, sleep tracking enabled)
  • Heavy Use: 4-6 days (continuous heart rate, frequent GPS usage, always-on display)
  • Standby Time: Up to 15 days
  • Power Saving Mode: Up to 30 days (basic time display only)
• Charging Method: Magnetic charging dock with pogo pin connector
• Charging Cable: USB-A to magnetic connector (cable length: ~1 meter)
• Charging Time: 1.5-2 hours for 0-100% charge
• Charging Interface: 2-pin magnetic connector (auto-aligns for easy charging)
• Battery Management: Smart power management with multiple battery saving modes

Sensors

• Heart Rate Sensor: Advanced PPG (Photoplethysmography) optical sensor
• Blood Oxygen (SpO2): Pulse oximetry sensor for blood oxygen saturation monitoring
• Accelerometer: 3-axis for step counting, activity recognition, and gesture control
• Gyroscope: For precise motion tracking and advanced activity recognition
• Sleep Monitoring Sensor: Comprehensive sleep tracking with sleep stage detection
• Breathing Sensor: For guided breathing exercises and stress monitoring
• Ambient Light Sensor: Automatic brightness adjustment based on environment
• Built-in GPS: May vary by model - some versions have GPS, others rely on connected GPS

Health & Fitness Features

• 24/7 Heart Rate Monitoring: Continuous tracking with high/low heart rate alerts
• Sleep Tracking: Monitors sleep stages (light, deep, REM) with sleep score and recommendations
• Blood Oxygen Monitoring: SpO2 measurement (manual and automatic during sleep)
• Stress Monitoring: Based on heart rate variability (HRV) with breathing exercises
• Women's Health: Menstrual cycle tracking and reminders (via app)
• Activity Tracking: Steps, distance, calories burned, active minutes, sedentary reminders
• Sports Modes: 100+ sport modes including:
  • Outdoor running, indoor running
  • Walking, hiking
  • Cycling (indoor/outdoor)
  • Swimming (pool/open water)
  • Yoga, pilates, meditation
  • Basketball, football, tennis, badminton
  • Workout, strength training
  • Treadmill, elliptical, rowing machine
  • Dance, aerobics, martial arts
  • Winter sports (skiing, snowboarding)
• Exercise Metrics: Duration, distance, pace, calories, heart rate zones, recovery time

Connectivity

• Bluetooth: Bluetooth 5.2 BLE (Bluetooth Low Energy)
• Bluetooth Range: Up to 10 meters (33 feet) unobstructed
• Compatible Devices: Android 5.0+ and iOS 10.0+ smartphones
• Required App: oraimo Fit (available on Google Play Store and Apple App Store)
• Notifications Support: Call, SMS, and app notifications (configurable in app)
• Music Control: Play/pause, skip tracks, volume control for phone music apps
• Camera Remote: Control phone camera shutter from watch
• Find My Phone: Make connected phone ring from watch
• Weather Sync: Displays current weather and forecast from phone

Notifications & Smart Features

• Call Management: Display caller ID, reject calls, quick reply with preset messages
• Message Display: SMS, WhatsApp, Facebook Messenger, Telegram, WeChat, etc.
• Social Media Alerts: Facebook, Twitter, Instagram, LinkedIn notifications
• Calendar Alerts: Meeting and event reminders synced from phone calendar
• Email Notifications: Gmail, Outlook, Yahoo Mail alerts
• App Notifications: Customizable app notification settings
• Alarm Clock: Multiple customizable alarms with vibration
• Stopwatch & Timer: Built-in stopwatch and countdown timer
• Sedentary Reminders: Move reminders after prolonged sitting
• Drink Water Reminder: Hydration reminders throughout the day
• Breathing Exercises: Guided breathing sessions for stress relief

Water & Dust Resistance

• Water Resistance Rating: IP68 certified
• Water Depth: Up to 1.5 meters (5 feet)
• Water Duration: Up to 30 minutes continuous submersion
• Suitable For: Hand washing, rain, shower, swimming in pools
• Swimming Tracking: Tracks swimming metrics (distance, strokes, SWOLF score, calories)
• Not Suitable For: Diving, hot water (sauna, hot springs), high-pressure water activities
• Care Instructions: Rinse with fresh water after swimming in chlorinated or salt water

Design & Build

• Case Material: Zinc alloy or aluminum alloy with matte finish
• Back Case: Polycarbonate with sensor array and charging contacts
• Screen Protection: Panda Glass - enhanced tempered glass with oleophobic coating
• Button: 1 physical button (multifunction: power on/off, menu navigation)
• Strap Material: Soft silicone with ventilation channels (sweat-resistant)
• Strap Mechanism: Standard quick-release pins (22mm)
• Display Shape: Rectangular with rounded corners (modern smartwatch design)
• Overall Design: Sporty yet elegant, suitable for daily wear and workouts

Companion App (oraimo Fit)

• App Name: oraimo Fit
• Platforms: Android (Google Play Store) and iOS (Apple App Store)
• Account Required: Yes (email or phone number registration)
• Data Sync: Automatic when in Bluetooth range, manual sync option
• Dashboard Features: Activity summary, sleep analysis, heart rate trends, SpO2 history
• Goal Setting: Customizable daily goals for steps, calories, active minutes
• Watch Face Gallery: 50+ downloadable watch faces (free and premium)
• Device Settings: Customize watch settings, notification preferences, health monitoring
• Firmware Updates: OTA (Over-the-Air) updates pushed through app
• Data Export: Export health data to Apple Health (iOS) or Google Fit (Android)

Watch Faces

• Pre-installed Faces: 8-12 default watch faces
• Downloadable Faces: 50+ additional faces available via oraimo Fit app
• Customization: Some faces allow customization of complications (data widgets)
• Face Categories: Analog, digital, minimal, fitness, information-dense, artistic
• Information Display: Time, date, day, battery, steps, heart rate, weather, calendar
• Always-On Faces: Limited selection of always-on display watch faces

Environmental Specifications

• Operating Temperature: -10°C to 45°C (14°F to 113°F)
• Storage Temperature: -20°C to 55°C (-4°F to 131°F)
• Operating Humidity: 10% to 90% RH (non-condensing)
• Atmospheric Pressure: 700 hPa to 1060 hPa
• Altitude: Up to 6000 meters (19,685 feet)

Warranty & Support

• Standard Warranty: 12 months limited warranty
• Warranty Coverage: Manufacturing defects in materials and workmanship
• Exclusions: Accidental damage, water damage, normal wear and tear
• Support Channels: Email support, online knowledge base, social media support
• Documentation: Digital user manual available in app and online
• Regional Support: Availability varies by country (oraimo has strong presence in Africa, Asia, Middle East)

What's in the Box

• oraimo Watch 5 Panda Glass smart watch
• Silicone strap (pre-installed on watch)
• Magnetic charging cable (USB-A to magnetic connector)
• User manual and warranty card
• Charging dock (integrated with cable or separate)

Performance & Usage

• Target Users: Fitness enthusiasts, health-conscious individuals, daily activity trackers, sports participants
• Best For: Daily activity tracking, sleep monitoring, heart rate monitoring, multiple sports tracking
• Heart Rate Accuracy: Good for resting and steady-state exercise, moderate for high-intensity interval training
• Sleep Tracking Accuracy: Good for sleep/wake detection, moderate for sleep stage differentiation
• Step Counting Accuracy: Good for walking and running, may miscount other arm movements
• GPS Accuracy: Moderate if built-in, good if using connected GPS from phone

Panda Glass Technology

• Glass Type: Panda Glass (proprietary tempered glass technology)
• Manufacturer: Typically refers to glass from Panda Group or similar manufacturers
• Durability: Enhanced scratch resistance (7-8H hardness similar to Gorilla Glass)
• Impact Resistance: Improved drop resistance compared to standard tempered glass
• Surface Coating: Oleophobic coating to resist fingerprints and smudges
• Transparency: High optical clarity with anti-reflective properties
• Comparison: Comparable to Corning Gorilla Glass or Schott Xensation glass

Comparison with Other Models

• oraimo Watch 5 vs Watch 4: Watch 5 has larger display, more sports modes, improved battery life
• oraimo Watch 5 vs Watch GT: Watch 5 has rectangular display vs circular on GT, more modern design
• oraimo Watch 5 vs Xiaomi Mi Band 7: Watch 5 has larger display, more watch-like appearance, similar features
• oraimo Watch 5 vs Huawei Band 7: Comparable features, oraimo may have better pricing in certain markets
• Panda Glass vs Standard Glass: Better scratch and impact resistance than standard tempered glass

Important Notes & Recommendations

• Phone Compatibility: Verify app compatibility before purchase (oraimo Fit app requirements)
• Battery Life: Actual battery life varies based on usage, settings, and connected features
• Water Resistance: IP68 is for fresh water only; avoid salt water and hot water exposure
• Heart Rate Accuracy: For medical-grade accuracy, use dedicated medical devices
• Strap Adjustment: Wear snugly but not too tight for accurate sensor readings
• Software Updates: Regularly update firmware through app for new features and bug fixes
• Charging: Use only provided charging cable; keep charging contacts clean and dry
• Temperature Sensitivity: Extreme temperatures can affect battery performance and sensor accuracy
• Panda Glass Care: While scratch-resistant, avoid contact with abrasive materials
• Value Proposition: Feature-rich smartwatch with premium glass protection at competitive price point
